Rinnai V53DEN Value Series Residential Natural Gas Tankless Water Heater – Outdoor

Product Description

The Rinnai V53DEN Value Series tankless water heater delivers a combination of comfort and value. Designed for outdoor installation, this natural gas unit provides an endless supply of hot water on demand. It features a compact design for easy installation and frees up valuable space. The electric ignition avoids wasted energy from a standing pilot light.

• Compact Design
• Energy-Efficient Promise
• Continuous Water for Multiple Applications

Product Highlights

This tankless water heater is energy-efficient, space-saving, and provides continuous hot water for residential applications. It is AHRI and CSA certified.

Product Information

Standard Information

• Brand: RINNAI
• Manufacturer Part Number: V53DEN
• Country of Origin: Japan

Technical Specifications

• Fuel Type: Natural Gas
• UPC: 766156011795
• Phase: 1
• Voltage: 120 Volts
• Product Depth: 7.9 in
• Product Width: 14.0 in
• Type: Tankless Water Heater
• CSA Listed: Yes
• Product Height: 21.8 in
• Frequency: 60 Hz
• Product Category: Water Heater – Tankless
• Medium: Hot Water
• Cold Water Inlet: 3/4 Inch
• Hot Water Outlet: 3/4 Inch
• NSF Certified: Yes
• AHRI Certified: Yes
• Vent Type: Vent Free
• Minimum Flow Rate: 0.4 GPM
• Gas Connection Size: 3/4 Inch
• Mount Type: Wall
• Application: Residential
• Product Line: Value Series
• Storage Type: Tankless
• Includes Pump: No
• Uniform Energy Factor: 0.81
• Maximum Input Capacity: 120000 BTU
• Minimum Input Capacity: 15500 BTU
• Combustion Type: Non-Condensing
• Ultra Low NOx Emissions: Yes
• Product Sub-line: High Efficiency (HE)
• Gas Conversion Kit: Not Available
• Installation Location: Outdoor
• Flow Rate at 40F Temperature Rise: 4.9 GPM
• Flow Rate at 45F Temperature Rise: 4.4 GPM
• Flow Rate at 50F Temperature Rise: 3.9 GPM
• Flow Rate at 60F Temperature Rise: 3.3 GPM
• Flow Rate at 70F Temperature Rise: 2.8 GPM
• Energy Factor: 0.82
• BTU (Max): 120000
• BTU (Min): 15500
• Max Flow (GPM): 5.3
• Min Flow (GPM): 0.3 GPM
• Depth (Inches): 8″
• Height (Inches): 22.5″
• Width (Inches): 14″
• Energy Star Rated: No
• Installation Type: Outdoor Only
• Cold Water Inlet (NPTM): 3/4″
• Hot Water Outlet (NPTF): 3/4″
• Gas Connection: 3/4″
• Dimensions: H: 21.8 in
• W: 14 in
• D: 7.9 in
• Manufacturer Trade Model Number – U.S.: V53DeN
• Recirculation Capable: No
• Residential Energy Star: No
• Domestic Hot Water Flow Rate (Maximum): 5.3 GPM 20.1 l/min
• Wi-Fi Capable: Yes
• SCAQMD Approved: Ultra Low NOx
• Activation GPM: 0.6
• Maximum Flow Rate: 5.3 GPM
• Minimum Gas Input: 15000
• Water Connection: 3/4″
• Water Pressure (Max): 150 PSI
• Water Pressure (Min): 20 PSI
• Max BTU Input: 120000
• Natural Gas Thermal Efficiency: 0.82
• Temperature (Max): 140 °F
• Temperature (Min): 115 °F
• Heating Technology: Non-Condensing
• Water Connection Type: MNPT
• Manufacturer Technology: Recirculation
